SHURE SM-7B dynamic studio microphone

SM7B dynamic microphone has a smooth, flat, wide-range frequency response appropriate for music and speech in all professional audio applications. It features excellent shielding against electromagnetic hum generated by computer monitors, neon lights, and other electrical devices. The SM7B has been updated from earlier models with an improved bracket design that offers greater stability. In addition to it's standard windscreen, it also includes the A7WS windscreen for close-talk applications.

SM7B Includes foam winscreen, close-talk windscreen, locking yoke mount.

Features:

Specifications:

Type

Dynamic



Frequency Response

50 to 20,000 Hz



Polar Pattern

Cardioid (unidirectional)



Impedance

Microphone impedance rating is 150 ohms (150 ohms actual) for connection to microphone inputs rated at 19 to 300 ohms.



Polarity

Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3.



Output Level (at 1,000 Hz)

Open Circuit Voltage*: -59.0 dB (1.12 mV)

*0 dB = 1 volt per Pascal



Electromagnetic Hum Sensitivity (Typical, Equivalent SPL/milliOersted)

60 Hz: 11 dB

500 Hz: 24 dB

1 kHz: 33 dB



Switches

Bass rolloff and mid-range emphasis: Slotted response selector switches. See Figure 3 in User Guide for bass rolloff and mid-range emphasis (presence boost) response.



Cartridge Shock Mount

Internal air-suspension shock and vibration isolator.



Microphone Connector

Three-pin professional audio (XLR)



Swivel Assembly

Integrated, captive nut for ease of attachment to stand, fits 5/8 in.-27 thread.



Case

Dark gray enamel aluminum and steel case with dark gray foam windscreen.



Dimensions

See User Guide



Net Weight

765.4 grams (1 lb, 11 oz).

• • Flat, wide-range frequency response for exceptionally clean and natural reproduction of both music and speech
  • Bass rolloff and mid-range emphasis (presence boost) controls with graphic display of response setting
  • Improved rejection of electromagnetic hum, optimized for shielding against broadband interference emitted by computer monitors
  • Internal "air suspension" shock isolation virtually eliminates mechanical noise transmission
  • Highly effective pop filter eliminates need for any add-on protection against explosive breath sounds, even for close-up vocals or narration
  • Now shipping with the A7WS detachable windscreen, designed to reduce plosive sounds and gives a warmer tone for close-talk vocals
  • Yoke mounting with captive stand nut for easy mounting and dismounting provides precise control of microphone position
  • Classic cardioid polar pattern, uniform with frequency and symmetrical about axis, to provide maximum rejection and minimum coloration of off-axis sound
  • Rugged construction and excellent cartridge protection for outstanding reliability
  • Replacement cartridge:  RPM106
• ONE MICROPHONE FOR EVERYTHING - Studio Recording, Home Recording, Podcasting & Streaming. The SM7B Is Trusted By The Worlds Leading Vocalists, Podcasters & Streamers.

• STUDIO VOCAL RECORDING - The SM7B’s Dynamic Cartridge With Smooth, Flat, Wide-range Frequency Response Produces Exceptionally Clean & Natural Reproduction Of Both Music & Speech.

• PODCAST & BROADCAST - Found In The Top Podcasting Studios Around The World, The SM7B Air Suspension Shock Isolation & Pop Filter Eliminate Both Mechanical Noise And Breathiness. So Words Get Through And The Rest Stays Out Of The Mix.

• STREAMING CONTENT - Professional Live Streaming Starts With A Microphone Capable Of Capturing Exceptionally Clean And Natural Reproduction Of Both Music And Speech. The SM7B Has Been A Pioneer In Such Abilities For Decades.
•
• PROFESSIONAL XLR CONNECTION - The XLR Connection Along With An Audio Interface Allows You More Control Over The Sound — Thus A Better Overall Sound Quality.
•
• CLASSIC CARDIOID PATTERN WITH UNIFORM CAPTURE - The SM7B Cardioid Pattern Is Designed To Reject Off-axis Audio, So You Can Sing Or Speak At A Comfortable Angle And It Captures The Sound, Just As You Want It, With Minimum Coloration.
•
• SHIELD YOUR SOUND - We Added Advanced Electromagnetic Shielding To Defeat Hum From Computer Monitors And Other Studio Equipment.
•
